Kyosho Mini Z Overlander Series Chassis
Kyosho is a company committed to Leisure. Kyosho’s
aim is to improve and expand the quality of life of our customers with the
development and creation of high class products to be enjoyed in their leisure
time.
|


- Straight from indoor to OFF-ROAD!
The hardtop off-roader now ready for the conquest of other territories:
"Mini-Z Overland Series".
Fully equipped with free moving deep stroke suspension, dampers on all four
wheels, special pattern hollow rubber tires and ample ground clearance for
rough road skills beyond your imagination.
The Overland is also a great hill climber and comes equipped with a diff
locking mechanism for maximum traction. A new beginning for indoor
motor sports has arrived !
- Newly developed unique suspension system.
- Equipped with bevel diff gears for smooth and stable
cornering.
- Damper units on all four wheels work together to hug the
contours of the road surface.
- Includes high performance FET amp with brake and reverse
function, and FET steering servo.
- Newly designed servo saver provides protection from hard
kickbacks from the surface.
- Ample approach and departures angles for aggressive
running power.
- Equipped with front under-chassis guard to protect the
chassis.
- Special pattern hollow rubber tires for great gripping
power.
- Pinion gears included allow four different gear ratios to
be chosen.
- Two fixed motor plate types mean no adjustment necessary
for gear teeth meshing.
- 6 different set-up variables make 4 different wheelbase
settings possible.
- Body comes complete with coloring, markings and door
mirrors.
- Special body mount system allows body to be
removed/attached simply by spreading the side panels.
- Possible to race twelve (12) cars against each other
(using narrow band frequencies).
|
Technical Data |
| Chassis Length |
136mm |
| Width |
70(73.74)mm |
| Height |
48mm |
| Track (F/R) |
60(63.64)mm |
| Total Weight |
approx. 210g |
| Tire Size |
φ 30 x 10mm |
| Wheelbase |
95mm |
| Gear ratio |
13.6 , 12.2 , 11.1 , 10.2:1 |
| Approach angle |
53° |
| Departure angle
|
40° |
| Move Wheel base |
95,100,105,110mm |
